Encoder Scales are one of our core specialties at Photo Reticle.
With over 20 years of dedicated manufacturing expertise in encoder scales, we have realized a wide variety of designs and form factors. We can produce encoder scales in lengths ranging from 2 mm to 800 mm, using materials such as glass, quartz, film, and aluminum alloy.
From standard OEM volume production to one-off mission-critical designs, we offer full capabilities including custom tooling, composite assemblies for easy installation, and comprehensive support for non-standard or highly specialized projects.
Bring us your toughest requirements—we turn precision concepts into reliable reality.
Glass Scales
We have extensive experience supplying precision components for ophthalmology and eye examination instruments.
Our team specializes in custom fabrication of medical device parts that incorporate fine grooves, ridges, channels, holes, windows, and other intricate geometric features.
Using micro-lithographic patterning combined with advanced processing techniques, we deliver versatile solutions for building microfluidic devices on quartz, soda-lime glass, and borosilicate substrates.
As with all our services, we can produce medical device components precisely to your custom-specified patterns and requirements.
Mylar Encoder Scales
Vestibulum arcu erat, imperdiet eu ex at, porta porttitor leo. Morbi auctor, sapien et gravida euismod, nisi justo ornare odio, id condimentum massa risus convallis ante. Ut venenatis arcu fermentum dictum ullamcorper. Aenean non ante id enim ornare luctus. Etiam pulvinar ipsum in convallis dignissim.
Reflective Mode Glass Scales
High-reflective chrome (HRC) coatings are available with over 60% reflectivity. Material options include high-reflective/transparent patterns or high-reflective patterns with an ultra-low reflective chrome layer on the backside to reduce unwanted reflections from mounting surfaces like aluminum. Gold coatings are also available for high-performance applications. Additionally, we can image scales with both transmissive and reflective patterns, if needed.
Transmissive Mode Glass Scales
We provide transmissive glass scales designed for OEM and high-performance applications. The standard configuration features soda-lime glass with low-reflective chrome (LRC) at an optical density of 2.8, which can be increased to over 5.0 if required. For applications requiring extreme precision, such as sine wave applications, ultra-flat quartz material can be specified. Additionally, borosilicate glass is available for high-temperature applications.
