About TL OPTIK | Precision Photolithography Manufacturing
Precision glass. Microscopic detail.
TL OPTIK is a precision glass and photolithography manufacturer based in Shaanxi, China. We make photomasks, encoder discs, reticles and calibration targets for instrument builders, industrial equipment manufacturers and research teams.
- Years in business
- 21+
- Custom projects
- 8,000+
- Units shipped annually
- 3.2M
Small patterns with a specific job
An encoder disc provides a position reference. A reticle puts a scale or aiming mark in the field of view. A calibration target helps check an imaging system. We manufacture the glass patterns behind these functions, with geometry and optical contrast suited to the instrument.
Glass, coatings and photolithography
Our work spans glass preparation, thin-film coating, laser direct writing and pattern inspection. We process fused silica and soda-lime glass, and also work with selected films and metals. Customers can order a polished substrate, a coated blank or a finished patterned component, depending on which steps they carry out themselves.
Prototypes and production orders
Some projects begin with one component for a new instrument; others call for a steady supply of an existing design. We support both. During development, we discuss how the pattern will be read, mounted and inspected. For repeat orders, the approved sample and drawing revision provide the reference for production.
The manufacturing behind the pattern
Glass preparation, coating and patterning take place here. Laser direct writing creates the fine features; inspection checks the finished pattern before it leaves production.
From polished substrate to inspected pattern.
Photomask blanks
Glass and fused silica substrates with chrome films and photoresist conditions selected for the next exposure or laser-writing step.
Patterned glass components
Encoder discs, linear scales, reticles, graticules, calibration targets and custom planar patterns produced from controlled artwork.
Inspection and metrology
Dimensional, surface, pattern and optical checks organized around the critical requirements in your specification.
A message from our Chief Engineer
I want TL OPTIK to understand what each component must solve for the customer. We start with the application, clarify the drawing and manufacturing details, and work toward a part that can be used with confidence.
